Quattrocode D700
Cuts and engraves dimple and laser keys in one single process.
Designed for specialist locksmiths, the Silca Quattrocode D700 cuts and engraves dimple and laser keys in one single process to improve the speed and quality of service to your customer. Thanks to the robot arm, which turns and positions the key automatically, keys are cut and engraved without needing to be manually re-positioned.
Quattrocode D700 Video -English Version
Product Details
Features
Cuts and engraves dimple and laser keys in one single process
Robot arm for automatic key rotation
20% faster key cutting in comparison to Triax Pro
Fully automated key cutting process
 Electronic clamp opening and closing
Integrated engraving
Automatic tracer positioning
Automatic cutter recognition using RFID
Reduce downtime
Easy cutter management
User-friendly software interface
Professional display
Full connectivity
Cleaner, safer and more practical working area
Many patent pending solutions
Â
Technical Data
Electricity supply: 100-240V - 50/60Hz
Cutter motor: 48VDC
Engraving motor: 24VDC
Key cutter: Cutter in hard metal
Engraving cutters: Cutter in hard metal
Tool speed: Key cutter: 25000 rpm - Engraving cutter: 22000 rpm
Clamping trolley movements: on 3 axes with ball screws activated by step motors on ground roller runners
Electronic clamp 03QC: Removeable and equipped with interchangeable jaws
Robot movement: On axis with ball screws activated by step motors on ground roller runners.
Runs: With clamp: axis X 80mm, axis Y 77mm, axis Z 40mm
Max dimensions: Height 680 mm, Width 502 mm, Depth 740 mm
Weight: 76,5 Kg
Functionality
Quattrocode D700 cuts and engraves dimple and laser keys in a single process. Integrates many exclusive solutions enabling automatic cutting cycles.
